concealed track channel

Name: concealed track channel
Brand: VISION ENTERPRISES
Price: 800.0 INR
Availability: InStock

Price 800.0 INR/ Piece

Get a Price/Quote

MOQ : 30 Pieces

concealed track channel Specification

Product Type
Concealed Track Channel

Material
Aluminum Alloy

Rated Power
Max 48W/m

Voltage
24V DC

Application
Track Lighting System, Commercial and Residential Interiors

Input Voltage
220-240V AC (with compatible driver)

Working Voltage
24V DC

Max. Current
2A

Lighting Source
Compatible with Track Light Modules (LED)

Color
Black / White / Custom finishes

No Of Bulbs
As per track installation

Base Type
Track Module

Insulation Layer
Integrated copper conductor strips

Mounting Type
Recessed / Surface Mounted

Weight
Approx. 500g per meter

Finish
Anodized / Powder-coated

Operating Temperature
-20C to 50C

Fire Rating
IP20 (suitable for indoor use)

Profile Dimensions
35mm x 18mm (example, can vary)

Channel Length
1 meter / 2 meter / Custom sizes

Compatibility
Suitable for 4-wire magnetic/adaptable track fittings

concealed track channel Trade Information

Minimum Order Quantity
30 Pieces

Delivery Time
5-7 Days

concealed track channel About

A recessed track channel is a flush-mounted metal housing installed directly into a ceiling or wall to support hidden, modular lighting or curtain systems. [1, 2, 3]

Key Features

Flush Aesthetic: Sits level with the drywall or plaster for a clean, trimless look.

Durable Build: Made from extruded aluminum for strength and heat dissipation.

Modular Setup: Accepts snap-in or magnetic LED lights, spotlights, and linear fixtures.

Concealed Wiring: Hides internal transformers and electrical tracks out of sight. [1, 2, 3, 4, 5]

Common Uses

Modern residential living rooms and kitchens.

Commercial offices and conference rooms.

Retail showrooms, art galleries, and museums. [1, 2, 3]

If you are planning an installation, tell me:

Are you working with drywall, a false ceiling, or concrete?
Are you looking for magnetic lighting tracks or curtain tracks?

Effortless Integration and Custom Sizing

Easily tailor the track channel for your project with 1 meter, 2 meter, or fully customized lengths. Whether you require recessed or surface mounting, this adaptable system seamlessly integrates into various ceiling or wall plans-ensuring a discreet, functional lighting solution for any space.

Robust Aluminium Build with Quality Conductors

Engineered with premium aluminum alloy, the channel is lightweight yet sturdy, offering longevity and easy handling during installation. Integrated copper conductor strips deliver reliable electrical contact and performance, supporting a rated power of up to 48W per meter.

Flexible Application for Modern Interiors

Perfect for both commercial and residential settings, the track channels accommodate 4-wire track light modules and come in black, white, or custom finishes. Low-profile dimensions and fire-resistant properties (IP20) make them a safe, elegant choice for a wide range of interior lighting needs.

FAQ's of concealed track channel:

Q: How is the concealed track channel installed-recessed or surface mounted?

A: The track channel can be installed in both recessed and surface-mounted configurations. The choice depends on the design requirements and available ceiling or wall space. For a seamless look, recessed installation is recommended, while surface mounting offers quicker installation and easier accessibility.

Q: What types of lighting modules are compatible with this channel?

A: This track channel is designed for 4-wire magnetic or adaptable track light fittings. It supports LED track light modules that have compatible track adapters and can operate on 24V DC, ensuring flexibility for a variety of lighting setups.

Q: Where is the optimal environment to use the concealed track channel system?

A: The concealed track channel is suitable for indoor environments such as commercial offices, retail spaces, and residential interiors. With an IP20 rating, it's recommended for dry, controlled spaces rather than moist or outdoor locations.

Q: What benefits does the integrated copper conductor provide?

A: The integrated copper conductor strips ensure safe, consistent electrical transmission throughout the channel. This design enhances performance reliability, reduces installation time, and supports the maximum rated power of 48W per meter.

Q: When is it advisable to choose custom channel sizes?

A: Custom channel sizes are recommended when standard lengths (1 meter or 2 meters) do not precisely fit your installation requirements. This is often the case in uniquely shaped rooms or intricate design layouts.

Q: How does the fire rating of IP20 influence track usage?

A: The IP20 fire rating means the track is protected against solid objects over 12mm but not against water. It assures safe operation in standard interior spaces but should not be used where moisture or direct water exposure is present.

Q: What is the process for connecting the track to a power source?

A: The concealed track channel connects to a 220-240V AC input via a compatible driver, which then supplies 24V DC to the track. Proper wiring and installation of the driver are crucial to ensure safe and efficient system operation.
